1997-2007 LS1 4.8L 5.3L 5.7L 6.0L 6.2L LS +7.400 Engine E1840P Sloppy Mechanics Stage 2 Cam Lifters Kit HT2148 12595365 12589226

Camshaft + Valve Lifter + Push Rod: Camshaft + Screw Set + Spacer Set with 16 Valve Lifters and 16 Valve Lifters+16 putters+Oil Pump+Timing chainSpecification:Part Number:HT2148,E-1840-P,12595365,12589226,ms98016t,PR614S M295 7.400,12499225,HL124,E1840P,12482063,12499224,12586484,551733,12585328,HL2148.Camshaft Compatibility:for Chevy LS-Series Engine 1997-UpNot for use with AFM/DODAutomatic's will perform best with a 2,600-2,800 Stall Converter. Putters:5/16" DIAMETER - 7.400" LENGTH - .080 WALL THICKNESSCamshaft RPM Range: 2200 to 5400 RPMCamshaft Intake Valve Lift: .585"Camshaft Exhaust Valve Lift: .585"Camshaft Advertised Intake Duration: 283°Camshaft Advertised Exhaust Duration: 286°Camshaft Intake Duration at .050": 228°Camshaft Exhaust Duration at .050": 230°Camshaft Lobe Separation: 112°Camshaft Intake Centerline: 108°Camshaft Cam Gear Attachment: 3-BoltNumber of Springs Per Valve: SingleOutside Diameter of Outer Spring (in): 1.290 in.Spring Coil Bind Height (in): 1.140 in.Damper Spring Included: NoSpring Install Load: 130lbsSpring Install Height: 1.800"Spring Open Height: 1.175"Spring Open Load: 318 lbsSpring Rate (lbs/in): 313 lbs./in.Inside Diameter of Outer Spring (in): 0.885 in.Valve Spring Style: BeehiveLifters Fitment includes:1999-2012 Trucks/SUVs 4.8L V-8 VIN-V,C,A1999-2007 Trucks/SUVs 5.3L V-8 VIN-T,Z,B1997-2004 5.7L LS1 V-82001-2005 5.7L LS6 V-81999-2010 Trucks/SUVs 6.0L V-8 VIN-U,K2005-2009 6.0L LS2 V-82008-2013 6.2L LS3 V-8; without AFM2006-2013 7.0L LS7 V-8Also fit Factory Roller 93-97 LT1, and 305-350 Chevy Engines.

• 🏎️[Cam & Lifter Kit Contents] 1 Intake Seal Set, 1 Valve Cover Seal Set, 1 Timing Cover Gasket Set, 1 Valley Cover Gasket, 1 One-piece Oil Pan Gasket, 1 Exhaust Header Gasket Set, 1 Rear Main Seal, 1 Rear Main Cover Gasket, 2 Multilayer Steel Cylinder Head Gaskets, 1 hevrolet Performance Parts Harmonic Balancer Bolt, 30 Cylinder Head Bolts, 16 HL-2148 Valve Lifters, 16 PAC-1218 Springs, 1 E-1840-P Camshaft, 1 M295 oil pump, 1 12556582 Timing chain.
• 🏎️[Vehicle Fitment] Compatible with GM Chevy 1997-2007 LS L92 L99 5.3L 5.7L 6.0L 6.2L1997-2007 V8 LSx Sloppy Stage 2.Not for use with AFM/DOD.Great for Cars, Trucks, SUV's, Street Rods, and LS Swaps.
• 🏎️[Cam Specs] 2200 to 5400 rpm; intake valve lift: .585"; exhaust valve lift: .585"; advertised intake duration: 283°; advertised exhaust duration: 286°; intake duration at .050": 228°; exhaust duration at .050": 230°; lobe separation: 112°; intake centerline: 108°; cam gear attachment: 3-bolt.
• 🏎️[16 Pcs Valve Springs] Outside diameter of outer spring (in): 1.290 in; inside diameter of outer spring (in): 0.885 in; spring coil bind height (in): 1.140 in; install load: 130lbs; install height: 1.800"; open height: 1.175"; open load: 318 lbs; rate (lbs/in): 313 lbs./in.
• 🏎️[Service] 1 Year Unlimited-mileage Quality Guarantee.We extremely value your satisfaction and strive to provide you good shopping exprience. Any further question, please feel free to contact us at any time.
