Truck-Mounted Crane Hoist Pickup Truck Crane 1100lbs 360°Swivel Truck-Mounted Crane with 12V Electric Winch&3 Boom Capacities Pickup Truck Jib Cranes for Construction Forestry Factory and Transport

DetailsDurable Hook: Made of alloy steel, it is durable and helps to hang goods without falling off easily.Winch Rope: The 24.6ft wire rope can meet your basic needs without buying another one.Steering Handle: It plays a turning function, allowing for convenient operation.Wire Rope Limit Pin: It ensures that the steel wire rope does not exceed its maximum tension range to avoid accidents such as breakage of the steel wire rope due to exceeding its load-bearing capacity during movement.ApplicationIt is mounted on a truck to lift generators, engines, compressors, wood, shop equipment, etc. It is suitable for the construction industry, forestry industry, and more.SpecificationMaterial: Q235 Steel Color: OrangeSurface Treatment: Polishing and Painting ProcessesAssembly Required: YesNumber of Items: 1Electric Winch Voltage: 12V Winch Rope Length: 7.5m/24.6ftBattery Model: 1 * AA Battery(Included) Electric Winch Capacity: 1587kg/3500lbLifting Arm Bearing Capacity: 100kg/220lb; 250kg/550lb; 500kg/1100lbCable Length: 1.3m/4.27ftRemote Control Distance: 15m/49.21ftLifting Arm Height Adjustment Range: 0°-20°-40°Lifting Arm Length Adjustment Range: 1.1m/3.61ft; 1.325m/4.35ft; 1.55m/5.09ftBase Rotation Angle: 360 °Gross Weight: 44kg/97lbNet Weight: 40kg/88.18lbSupport Pole Height: 1.05m/3.45ftBase Size: 24*24cm/9.45*9.45in Installation Hole Diameter: 17mm/0.67inProduct Size(L&H): 1.14*1.05-2.1m/3.74*3.45-6.89ftPackage Size: 105*30*25cm/41.34*11.81*9.84inPackage Included1*Truck-Mounted Crane Hoist1*Electric Winch1*Remote Control AssemblyAll Accessories Required for InstallationNotes1. Please read the label carefully before using it. Please stay away from the area around the wire rope and drum.2. Please pull out the rope in the direction of the arrow. Please do not use it for overloaded lifting or moving personnel.3. Please take a 10-minute break after 30 minutes of continuous work. Please turn off the power switch when not in use.4. Please allow the slight color difference caused by the shooting light and the 1-3 cm error due to manual measurement, and make sure you do not mind before ordering.

• 【Adjustable Design】: You can adjust the lifting arm length at 3.61/4.35/5.09ft and angle at 0°/20°/40° and the crane height from 3.45-6.89ft to meet your different construction environments and usage needs. The 360° rotatable base also brings more convenience during the lifting process.
• 【Stable Structure】: The large square base(9.45-in in length) with four screw-reinforced installation holes makes the product highly stable, so you don't have to worry about shaking or collapsing during the production process.
• 【User-friendly Design】: The equipped remote control allows you to control the electric winch within a distance of 49.21ft, and it can also control the up and down directions (one is up, the other is down)greatly improving operation convenience.
• 【Strong Load-bearing Capacity】: The maximum 1100 lbs load capacity of the truck-mounted crane and 3500 lbs load capacity of the electric winch allow you to use this product with confidence to lift heavy objects such as engines, tables, and shop equipment.
• 【Effortless Cleaning】: The smooth surface after a painting treatment finish allows you to simply clean this product with a wet cloth.
